MX2800 Multiplexer Chassis - M13 multiplexer - 1200290L1
The MX2800 is an M13 multiplexer that consolidates T1 and E1 signals into a T3 circuit. This unit provides a cost-effective, versatile tool for combining independent T1s, E1s, or a combination of the two over the same T3 circuit. The MX2800 houses two hot-swappable controller cards which provide 1:1 redundancy for the T1 and T3 signals, as well as the T3 connections.
Compact and Powerful
Embedded simple network management protocol (SNMP) and Telnet are available through the modem port using serial line internet protocol/point-to-point protocol (SLIP/PPP) or through the 10Base-T Ethernet port. Using the Management Information Base II (MIB II), RFC 1407 standards, and an ADTRAN enterprise MIB, the MX2800 can be configured, monitored, and diagnosed with standard SNMP network management programs such as Hewlett Packard’s HP OpenView™ and Cabletron’s Spectrum®. In addition, the SysLog Host Daemon allows remote monitoring, collecting, and logging of MX2800 events in realtime. This information is useful during installation setups and/or troubleshooting. Complete configuration, loopbacks, and performance monitoring are available through SNMP, Telnet, or a VT100 terminal interface. This connection can be made via Ethernet, a local EIA-232 link, or through the built-in V.34 modem. The modem can dial out a “cry for help” for units located in unmanned facilities. The MX2800 is designed for installation in a 19-inch or 23-inch rack.
- M13/STS-1 multiplexer chassis
- Houses hot-swappable controller cards
- Supports SNMP, Telnet, and TL1 management
- Quick, easy installation
- Connectorized backplane
- Capable of backhauling multiple service types (T1/E1)
- Fits either 19" or 23" racks
- Houses AC and DC Power Supply Versions
- NEBS Level 3 compliant
- Supports G.747 for the transport of up to 21 E1s
- Houses dual load-sharing redundant power supplies
