2609GN - FiberLAN Desktop GPON ONT




Next-generation FiberLAN PoE ONT optimized for desktop and wall-mount installations using DZS leading-edge GPON technology.

The DZS 2609GN series GPON ONTs is the next generation of ONTs designed for Enterprise and Hospitality deployments requiring secure, Ethernet-only connectivity with a compact footprint. The 2609GN GPON ONTs provide customers with 8 x 10/100/1000BaseT LAN ports, all with PoE++ capability, allowing for convenient connections to IP phones, PTZ cameras, wireless access points, and remote switches. Configurable per-port PoE limits help direct power where it is needed. The 2609GN LAN ports can be separated into different services allowing the configuration of dedicated ports for IP video and data for one or more business workgroups or departments. Unique VLANs may be configured per user to ensure full isolation of each department’s data traffic.

The DZS 2609GN includes one SC/APC GPON interface, four 10/100/1000Base-T ports, all with PoE++ capability allowing for powered connections to IP devices. Configurable per-port PoE limits up to 60W on any port and 240W per system. The 2609GN is powered by a nominal 48-56VDC source from a centralized power distribution system that may also provide battery backup.



     Zhone - 2609GN FiberLAN Desktop GPON ONT



Key Features

  • Supports 2.5Gbps/1.25Gbps (Downstream/Upstream) with integrated GPONWAN interface
  • Eight gigabit multi-rate 10/100/1000M Ethernet interfaces
  • 802.3af, at, and bt PoE++ compliant
  • Up to 240W of PoE power per ONT
  • Enterprise LAN features (802.1x, LLDP)



Service Scenario

The FiberLAN GPON network consists of an Optical Line Termination (OLT) located in a central location, and a set of Enterprise-grade Optical Network Terminals (ONTs). All Ethernet LAN ports can be separated into different services allowing the configuration of dedicated ports for IP video and data for one or more business workgroups or departments. Unique VLANs may be configured per user to ensure full isolation of each department's data traffic.

With LLDP-MED support for voice VLAN advertisement, 802.1x authentication, and DZS Dynamic VLAN Mapping capability for handling complex sets of packet classification rules, operators can expertly manage traffic on each ONT LAN port to provide optimum customer experiences.




Data Sheet

2609GN - FiberLAN Desktop GPON ONT
