TX64 (Rail)

Industrial Wireless Router

5G, 4G, and 3G Ruggedized Router  -  USA and Canada

Compact, ruggedized LTE router with Industrial feature set and Rugged, reliable, cost-effective connectivity for critical industrial applications.

Ideal for challenging rail transportation environments, theTX64 5G Rail router offers 5G/4G/3G cellular connectivity with true enterprise-class routing, security, firewall, and integrated VPN. It offers a flexible interface design with an integrated Wi-Fi access point and client, USB, serial, inertial-guided GNSS, Bluetooth® and 4-port Gigabit Ethernet switch, as well as a variety of configurations options.

5G is a game-changer for the rail industry. Until now, the speeds needed to securely move massive amounts of data quickly were reserved for wired networks. But today, with the rapid expansion of 5G (with LTE fallback), this fully rail-certified device delivers 5G performance, either as a primary or failover connection. Customers and suppliers alike will begin to expect 5G connectivity whether it is for other onboard equipment applications or the information being provided to riders. Paving the way for compatibility with FRMCS standards, this first industry-standard 5G rail-rated device prepares you for the future today.

The TX64 5G Rail is equipped with precision train positioning via an Untethered Dead Reckoning (UDR) module that reports location data more accurately by taking into account acceleration, speed, and angular rate. Regardless of issues with traditional GNSS in certain weather conditions or tunnels, UDR allows you to monitor the train’s exact positioning and speed, optimize each train’s location and prevent collisions without the use of additional onboard systems.

Key Features

• High-speed 5G NR cellular radio with 4G LTE-Advanced Pro Cat 20 and 3G fallback
• FirstNet Ready™ for primary responder communication
• WR44 RR drop-in replacement and upgrade
• Wired Gigabit M12 Ethernet (4-port) for onboard systems
• Dual concurrent 867 Mbps 802.11ac Wi-Fi interfaces
• Untethered Dead Reckoning combines GNSS with inertial sensors
• Securely deploy, monitor, and control devices with Digi Remote Manager®
• Cryptographic co-processor with secure key generation and storage

TX64 Rail Series Details

• Automated Network Monitoring: To keep tabs on dozens, hundreds, or thousands of active connected devices requires network monitoring software. Human eyes can't keep up. With Digi RM remote monitoring tools, you're in command. As your IoT device management platform, Digi RM watches your network for disruptions and intrusions, and lets you know when you need to take action. Set alerts for important conditions. Get reports on network performance. Check on any device, anywhere, anytime.
• Firmware Updates: Today's IoT devices are smarter, more feature-rich, and have more tasks to perform at the edge. And they are not static. You may need to update the firmware to enhance functionality, download custom scripts, keep your devices in compliance with corporate security policies, or deploy patches for threats to IoT security. Digi Remote Manager puts the network management tools in your hands to deploy firmware updates or send files to your devices in minutes, even if you have a network of many thousands of devices. Manage your dynamic network with a few clicks. Keep your devices secure.
• Configuration Management: Digi Remote Manager has what other IoT device management platforms don't: the ability to configure all of your devices at once, make individual configuration changes, and still manage those specialized configurations in groups. Create a group and individual configurations. Deploy rapidly and accurately. Let Digi RM monitor device security
• Detection and Troubleshooting: Digi RM is always on, even during your network manager’s off hours. As your network monitoring solution, Digi RM lets you know when issues arise, sending alerts and delivering reports so your team can rest easy. At any time, they can gain the insights needed on the health of the entire network or individual devices and remotely troubleshoot, test, and reboot devices as needed. Put network monitoring tools to work for you, so you can work smarter.

TX64 Rail Series Applications

• Train
• Fleet
• Motor Vehicle
• Trucking
• Fare Collection
• CAD/AVL data
• Camera Log Backhaul
• Passenger Wi-Fi Access
• FirstNet

Product Specifications

*Transfer rates are network operator independent

**Standard 3-year warranty upgradeable to 5 years with the purchase of a Digi Remote Manager® Premier 5-year subscription applicable to the product purchased only at the time of product purchase and with product registration at that time in Digi Remote Manager.

For a comprehensive list of operating system features, please visit www.digi.com/solutions/by-technology/dal-operating-system/features.

DATA SHEETS

Data Sheet:  TX64 Rail

Data Sheet:  Product Models Feature Comparison
