TeraStation 6000 Series + Snapshot
Rackmount NAS
High-Performance Storage Defense Against Cyber Threats +Snapshot - Hard Drives Included
This family of Network Attached Storage devices is available in rackmount and desktop options, with capacities ranging from 8TB up to 32TB. The TS6000 comes with hard drives included. Desktop & Rackmount form factors offer partially populated options for businesses to buy-in at a lower price with room for future data growth. The TS6000 also uses snapshots to further protect your data. By creating a full virtual copy of your local data that you can easily restore at any time, the TS6000’s snapshot feature is a true game-changer to combat the common occurrences of essential files being overwritten or deleted due to user error. Snapshots are also an effective tool to curb the rising threat of ransomware. In the event of a ransomware attack, you can simply choose to restore specific files to a previously uninfected state, or even revert the entire storage volume to a previous state that has not been infected.
The TS6000 also features additional data protection. The new model now utilizes copy-on-write to further reduce backup errors when updating files. In addition, the TS6000 now boasts direct iSCSI backup and backup capability, a key backup feature where you can directly connect a TS6000 to another TS6000 device on the network and back up its data. With this method, data is transferred through a separate, closed network, which significantly reduces server bandwidth and workload. This family is VMware Certified for iSCSI. In the event of a hard drive issue, the TS6000 new duplex firmware solution allows the system to boot from the NAND flash memory on the system board instead of the hard drive, which keeps operations stable while allowing you to run diagnostics and repair the damaged firmware on the hard drive. This allows the firmware to be recovered without losing data in most cases, adding an extra layer of data security.
Features:
- Snapshot protects data from cyber threats
- iSCSI backup target with iSCSI replication capable
- NAS-grade hard drives included
- 3rd party cloud integration for hybrid cloud
- Up to 32TB Capacity
- 10GbE port for faster data transfer speeds
- 256 bit AES encryption for data security
Specifications
MODELS
TS6400RN |
|
Part Numbers |
TS6400RN1604 (4 X 4TB) |
INTERNAL HARD DRIVES
Number of Drive Bays | 4 |
Number of Included Drives | 2 or 4 |
Capacity Range | 8 to 32 TB |
Drive Interface | SATA 6 Gbps |
Supported RAID | 0/1/5/6/10 (Default 5) |
USB INTERFACE
Standards Compliance | USB 3.0 |
Connector Type | A type |
Number of Ports | 2x USB 3.0 |
Data Transfer Rates | 5 Gbps |
PERFORMANCE
CPU | Intel® Atom C3538 |
Memory | 8GB DDR4 with ECC |
ENVIRONMENTAL & POWER
Power Consumption |
Max 85W Data Transfer 62W Idling 55W |
Power Supply | Internal AC 100-240V Universal 50/60Hz |
Operating Temperature | 32° - 104°F (0° - 40°C) |
Operating Humidity | 10 - 85% non-condensing |
SHIPPING
Product Dimensions (L x W x H) |
16.9 x 16.9 x 1.7 in |
Product Weight | 19.6 lbs |
Package Dimensions (L x W x H) | 23.03 x 21.26 x 7.87 in |
Package Weight | 29.1 lbs |
LAN INTERFACE
Standards Compliance | IEEE802.3an (10GBASE-T), IEEE802.3bz (5GBASE-T/2.5GBASE-T), IEEE802.3ab (1000BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3 (10BASE-T) |
Number of Ports | 1 (10GBASE-T), 2 (1000BASE-T) |
Data Transfer Rates | 10 Gbps / 1000 Mbps / 100 Mbps / 10 Mbps |
Supported Protocols | TCP/IP |
Network File Services | CIFS/SMB, AFP, FTP, SFTP, NFS, SNMP |
Connector Type | RJ-45 |
OTHER
VMware Compatibility | iSCSI & NFS |
Client OS Support |
Windows® 10, Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2016, Windows Server® 2012, Windows Server® 2012R2, Windows Server® 2008, Windows Server® 2008R2, Mac® OS® X 10.11 or later |
Compatible Hard Drives | OP-HD2.0N, OP-HD4.0N, OP-HD6.0N, OP-HD8.0N |
Optional Warranties | 3YKYD30 - 3yr Keep Your Drive, 5YKYD30 - 5yr Keep Your Drive, 3YNBD30 - 3yr Next Business Day, 5YNBD30 - 5yr Next Business Day |
Included Software | NASNavigator2, NovaBACKUP® Buffalo Edition (one server and ten workstation licenses) |
Box Contents | TeraStation™, Quick Setup Guide, 6a Ethernet Cable , Rail Kit with Mounting Brackets and Screws, AC Cable, and Warranty Statement |
Have more questions about Network Attached Storage products and solutions? Call us at 410-583-1701 or email us at questions@pulsesupply.com.
