TeraStation 5010 Series
Desktop NAS
High-Performance Storage Defense Against Cyber Threats +Snapshot - Hard Drives Included
The TeraStation 5010 is a high performing business-class network-attached storage (NAS) featuring powerful processing power and native 10GbE support. Accelerate speed and overall performance with business class processing power supporting 100 concurrent sessions with sustained performance even during heavy-load operations. The TS5010 family comes with NAS/ Enterprise-grade hard drives* included with partially populated models to fit today's needs while planning for tomorrow's storage concerns. Partially populated models include 4 & 8 bay desktop and 4 & 12 bay rackmount units.
TeraStation 5810DN is an eight-bay desktop system featuring a native 10GbE port. Base models ship with NAS-grade hard drives allowing future scalability. Users with defined storage needs can order fully populated models with eight NAS-grade hard drives up to 64TB of storage capacity. TeraStation 51210RH is a 2U rackmount system offering scalability. Base models ship with four enterprise-grade hard drives allowing users to meet future storage demands by simply adding additional hard drives. Users with defined storage needs have the ability to select fully populated systems with twelve enterprise-grade hard drives included up to 192TB total storage capacity. TeraStation 51210RH includes dual 10GbE ports and a rail kit for easy deployment.
Features:
- Premium grade components (NAS & Enterprise-grade hard drives)
- Up to 2 native 10GbE ports*
- Quad-core Annapurna processor
- Industrial-grade internal power supply
- Premium metal chassis with Kensington security slot and front panel lock*
- Boot Authentication - locks device until authenticated on the network in case of theft
- Duplex Firmware for reduced system downtime
- Pre-configured RAID enabled systems
- VMware certified (iSCSI & NFS certifications)*
- 3rd party cloud integration for hybrid cloud
- Up to 192TB Capacity
- 256 bit AES encryption for data security
- 24/7 North American based support
- Novastor Business Essentials server and workstation licensing
- Use cases include: Virtualized storage target, Offsite disaster recovery, and File sharing & local backup
*TS5210DN, TS5410DN, TS5810DN, and TS5410RN ship with NAS-grade hard drives. TS51210RH ships with enterprise-grade hard drives and two native 10GbE ports.
*TS5210DN, TS5410DN, TS5810DN include Kensington security slot and front panel lock
Specifications
TS5210DN
|
TS5410DN
|
TS5810DN
|
| Part Numbers |
TS5210DN0402
TS5210DN0802
|
TS5410DN0804
TS5410DN1604
TS5410DN2404
TS5410DN3204
TS5410DN0402
TS5410DN0802
TS5410DN1602
|
TS5810DN1604
TS5810DN3204
TS5810DN3208
TS5810DN6408 |
| Form Factor |
Desktop |
Desktop |
Desktop |
INTERNAL HARD DRIVES
| Number of Drive Bays |
2 |
4 |
8 |
| Number of Included Drives |
2 |
2 or 4 |
4 or 8 |
| Capacity Range |
4, 8 TB |
4, 8, 16, 24, 32 TB |
16, 32 or 64 TB |
| Drive Interface |
SATA 6 Gbps |
SATA 6 Gbps |
SATA 6 Gbps |
| Supported RAID |
0/1/JBOD (Individual Disks) |
0/1/5/6/10/JBOD (Individual Disks) |
0/1/5/6/10/JBOD (Individual Disks)
|
USB INTERFACE
| Standards Compliance |
USB 3.0 |
USB 3.0 |
USB 3.0 |
| Connector Type |
A type |
A type |
A type |
| Number of Ports |
2x USB 3.0 |
2x USB 3.0 |
3x USB 3.0 |
| Data Transfer Rates |
5 Gbps |
5 Gbps |
5 Gbps |
PERFORMANCE
| CPU |
Annapurna Labs® Alpine Processor
AL314 (1.7 GHz Quad-Core) |
Annapurna Labs® Alpine Processor
AL314 (1.7 GHz Quad-Core) |
Annapurna Labs® Alpine Processor
AL314 (1.7 GHz Quad-Core) |
| Memory |
4 GB DDR3 with ECC |
4 GB DDR3 with ECC |
4 GB DDR3 with ECC
|
ENVIRONMENTAL & POWER
| Power Consumption |
Max 85W
Data Transfer 45W
Idling 32W
|
Max 85W
Data Transfer 56W
Idling 45W
|
Max 150W
Data Transfer 108W
Idling 87W
|
| Power Supply |
Internal AC 100-240V Universal 50/60Hz |
Internal AC 100-240V Universal 50/60Hz |
Internal AC 100-240V Universal 50/60Hz |
| Operating Temperature |
32˚ - 104˚F (0˚ - 40˚C) |
32˚ - 104˚F (0˚ - 40˚C) |
32˚ - 104˚F (0˚ - 40˚C) |
| Operating Humidity |
10 - 85% non-condensing |
10 - 85% non-condensing |
10 - 85% non-condensing |
SHIPPING
Product Dimensions
(L x W x H) |
9.06 x 6.69 x 6.69 in |
9.06 x 6.69 x 8.46 in |
11.81 x 8.46 x 9.06 in |
| Product Weight |
10.58 lbs |
15.43 lbs |
20.72 - 27.55 lbs |
| Package Dimensions (L x W x H) |
14.09 x 12.24 x 12.60 in |
14.06 x 12.17 x 14.29 in |
216.54 x 13.78 x 13.78 in |
| Package Weight |
13 lbs |
19.62 lbs |
25.13 - 31.96 lbs |
LAN INTERFACE
| Standards Compliance |
IEEE802.3an (10GBASE-T), IEEE802.3bz (5GBASE-T/2.5GBASE-T), IEEE802.3ab (1000BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3 (10BASE-T) |
| Number of Ports |
1 (10GBASE-T)*, 2 (1000BASE-T)
*TS51210RH includes an additional 10GBASE-T port |
| Data Transfer Rates |
10 Gbps / 1000 Mbps / 100 Mbps / 10 Mbps |
| Supported Protocols |
TCP/IP |
| Network File Services |
CIFS/SMB, AFP, FTP, SFTP, NFS, SNMP |
| Connector Type |
RJ-45 |
| VMware Compatibility |
iSCSI & NFS |
|
Client OS Support
|
Windows® 10, Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2016, Windows Server® 2012, Windows Server® 2012R2, Windows Server® 2008,
Windows Server® 2008R2, Mac® OS® X 10.9 or later |
| Compatible Hard Drives |
OOP-HD2.0N, OP-HD4.0N, OP-HD6.0N, OP-HD8.0N |
| Additional Power Supply |
OP-PU-10R2UWR (TS51210RH ONLY) |
| Optional Warranties |
3YNBD20 - 3yr Next Business Day, 3YNBD10 - 3yr Next Business Day, 3YKYD40 - 3yr Keep Your Drive, 3YKYD30 - 3yr Keep Your Drive, 3YKYD20 - 3yr Keep Your Drive, 3YKYD10 - 3yr Keep Your Drive, 5YNBD40 - 5yr Next Business Day, 5YNBD30 - 5yr Next Business Day, 5YNBD20 - 5yr Next Business Day, 5YNBD10 - 5yr Next Business Day, 5YKYD40 - 5yr Keep Your Drive, 5YKYD30 - 5yr Keep Your Drive, 5YKYD20 - 5yr Keep Your Drive, 5YKYD10 - 5yr Keep Your Drive |
| Included Software |
NASNavigator2, NovaBACKUP® Buffalo Edition (one server and ten workstation licenses) |
| Box Contents |
TeraStation™, Quick Setup Guide, AC Cable, Front Panel Key**, and Warranty Statement |
Have more questions about Network Attached Storage products and solutions? Call us at 410-583-1701 or email us at questions@pulsesupply.com.
