PS-300D & PS-300X - Voice Signaling Converter

SS7, C7, R2, ETSI PRI, and V5.2 signaling
E1 PSTN INTERFACE

This high-performance, low-cost signaling converter allows any conversion between SS7, R2, Qsig, V5.2, or ETSI PRI. Housed in a low profile 1U rackmount chassis, the PS-300D supports up to (16) E1s with up to (8) Spans. Available in balanced RJ-45 or Dual BNC ports.

Supports multiple signaling links and advanced features like black and white lists, Caller ID manipulation, and virtual caller. Supports routing tables for link routing. AC or DC Power Supply.

Product Information

Supports flexible voice signaling conversions

A signaling converter is a device that enables connectivity between different signaling networks by resolving signaling differences with legacy switches and new network equipment (such as VoIP Gateways).

This signaling converter makes inter-conversion from E1 to E1, which converts any signaling between M3UA, Sigtran, SS7, ISDN PRI, Q.SIG, V5.2, R2/CAS, and DPNSS.

Several models are available for the PS-300D with support for 2, 4, 8, or 16 ports, makes bidirectional conversion between 1 E1 and 1 E1, 2 E1 and 2 E1, 4 E1 and 4 E1, or 8 E1 and 8 E1. The PS-300X high-density chassis version can support up to 50 E1 Spans and up to 64 signaling links.

Maintenance and Diagnostics

Multiple maintenance features enable quick and cost-effective resolution of network problems. Trace functionality is available to aid in troubleshooting configuration and network problems. Visual alarms allow for local monitoring. The graphical-based management system allows for programming and troubleshooting.

Key Features

• SupSignaling support: SS7, ISDN PRI, Q.SIG, V5.2, R2/CAS, DPNSS
• Interface Connector: up to 16 E1, 1 10/100M network, 1 RS232 console (PS-300D)
• Interface Connector: up to 100 E1, 1 10/100M network, 1 RS232 console (PS-300X)
• Link: up to 16 SS7 links, 16 PRI (PS-300D)
• Link: up to 64 SS7 links, 100 PRI (PS-300X)
• Switching Volume: 2048 x 2048
• Clocking accuracy: stratum 3 Clock
• Clocking Source: E1, internal
• Resource: 256 Voice channels, 256 meeting channels, 256 DTMF channels FSK inspection and delivery

Applications

• Signaling Converter
• E1 Recording System
• Multi-Router Connections
• SS7 Collection and Consolidation
• Call Management Control
• PBX Interface Conversion
• Automatic Forward and Roaming Gateway
• MAP Messaging Converter
• Local Ringtone Platform

Specifications

 PS-300D Data Sheet

 PS-300X Data Sheet
